Kennedy KEN0268460K SET OF 19 HSS-COBALT S/SDRILLS 1-10mm x 0.50mm
Kennedy KEN0268460K SET OF 19 HSS-COBALT S/SDRILLS 1-10mm x 0.50mm
Description
Kennedy KEN0268460K SET OF 19 HSS-COBALT S/SDRILLS 1-10mm x 0.50mm
HSS-Co 5% Metric Jobber Drill Set – 19 Pieces
19 Piece Metric: 1.0-10.0mm x 0.5mm
Heavy duty drill made of 5% cobalt material with excellent heat resistance. To drill steels with tensile strength up to 1,400 N/mm2, very hard bronze, stainless steels as well as heat and acid resistant steels. Point angle: 135°. Helix angle: normal. Web thickness: strengthened. Relief angle: normal. Tolerance of diameter: h8. Tolerance of shank: f11. Supply unit. All diameters – 1 pce. Manufacturing Standard: BS 328, DIN 338B.
Specification
| Property | Value |
|---|---|
| Brand | Kennedy |
| Case Type | Metal Case [txt] |
| Cutting Direction | Right Hand [txt] |
| Diameter Range | 1.0mm to 10.0mm by 0.5mm Increments [txt] |
| Drill Length Type | Standard Length [txt] |
| Drill Size Included | 1.0; 1.5; 2.0; 2.5; 3.0; 3.5; 4.0; 4.5; 5.0; 5.5; 6.0; 6.5; 7.0; 7.5; 8.0; 8.5; 9.0; 9.5; 10.0 mm |
| EAN13 Barcode | 5036140072763 |
| eCl@ss Code | 21010101 |
| Finish/Coating | Bronze [-] |
| Flute Construction | Ground Flute [txt] |
| Material | Cobalt High Speed Stee [txt] |
| Maximum Drill Size | 10.00 mm |
| Minimum Drill Size | 1.0 mm |
| Number of Pieces | 19 [#] |
| Overall Depth | 34 |
| Overall Length | 154 |
| Overall Weight | 0.62 |
| Overall Width | 111 |
| Size Increment | 0.5 mm |
| Standards Met | BS 328;DIN 338B [txt] |
| Supplier Part No. | 0268460K |
| System of Measurement | Metric [txt] |
| UNSPSC Code | 23241634 |
Further Information
| Property | Value |
|---|---|
| Case Type | Metal |
| Material | Cobalt High Speed Steel |
| Product Number | |
| Number of Pieces | 19 |
| Cutting Direction | Right Hand |
| Standards Met | BS 328 DIN 338B |
| Finish/Coating | Bronze |
| System of Measurement | Metric |
| Drill Length Type | Standard Length |
| Flute Construction | Ground Flute |
| Minimum Drill Size | 1 mm millimetre in. inch |
| Maximum Drill Size | 10 mm millimetre in. inch |
| Drill Size Included | 1mm to 10mm x 0.5mm |
| Size Increment | 0.5 mm millimetre in. inch |
Additional information
| Weight | 1 kg |
|---|
