Description
Kobe KBE2702090K FAG050M 50mm MINI GRINDER
FAG050m – 50mm Mini Angle Grinder
FAG050m
For metal dressing, rust removal, weld preparation and automotive
bodywork fabrication in hard to reach areas. Speed regulator. Safety
release throttle. Heavy duty disc guard. Side exhaust. Ball bearing
construction. Supplied with: 2x A60 (KEN230-0040K), 1x A80
(KEN230-0050K) and 1x A120 (KEN230-0060K) 50mm grinding discs.
Disc size: 50 x 4 x 9.6mm (2″ x 5/32″ x 3/8″).
Air inlet thread: 1/4″ NPT. Minimum air hose
size (ID): 3/8″ (10mm).
Air pressure: 90psi/6.3bar.
Air consumption: 4cfm*.
Sound pressure level: 83dBA.
Sound power level: 92dBA.
Vibration level: 1.7m/s2.
Overall length: 140mm.
*Based on a 15 second cycle per minute average use.
Specification
| Property |
Value |
| Brand |
Kobe Green Line |
| EAN13 Barcode |
5036140019430 |
| eCl@ss Code |
21060900 |
| Free Speed |
20000 rpm |
| Overall Depth |
85 |
| Overall Length |
210 |
| Overall Weight |
0.835 |
| Overall Width |
90 |
| Supplier Part No. |
2702090K |
| UNSPSC Code |
27131511 |
| Weight Each |
530 g |
Further Information
| Property |
Value |
| Collet Size |
mm millimetre in. inch |
| Material |
Aluminium with Grip |
| Overall Height |
83 mm millimetre in. inch |
| Overall Length |
133 mm millimetre in. inch |
| Overall Width |
60 mm millimetre in. inch |
| Product Number |
FAG050m |
| Type |
Air Mini Die Grinder |
| Weight |
g gram 0.53 kg kilogram |
| Includes |
(4)Grinding Discs |
| Horsepower |
0.30 hp horsepower |
| Maximum No Load Speed |
20,000 rpm revolutions per minute |
| Air Pressure |
90 PSI pounds per square inch |
| Air Consumption |
4 CFM cubic feet per minute L/min litres per minute |
| Throttle Features |
Safety Release Throttle |
| Air Inlet Size |
1/4NPT |
| Compatible Hose Inner Diameter |
10 mm millimetre |
| Grinder Orientation |
Angled |
| Grinder Angle |
90 ° degree |
| Speed Features |
Variable Speed |
| Exhaust Location |
Side |
| Compatible Wheel Diameter |
50 mm millimetre 2 in. inch |
| Manufacturer Guarantee |
|
| Noise/ Vibration Information |
